Supercharger Development
Status
Friday, January 20th, 2011
Latest
update
Supercharger manifold welded and in position.
Still to do is finish
cooler plates (2 of 4 done already), SC outlet
plumbing,
driveshaft machining, new SC inlet, and manifold
supports.

Release Goal - Late Spring 2012.
*********************************************************
Friday, January 13th, 2011
Here is the upper part of the manifold.
Welding it tomorrow. Lower part is
done and is offset to one side slightly (to fit
the engine bay).
This should be fitted to the car by the end of
next week.

And here is what the inside looks like.
Bellmouthed runners
will encourage laminar flow to the valve.

*********************************************************
Monday, November 14, 2011
We are continuing to do prototype development on
the Lysholm 1600AX; however since Lysholm's bankruptcy last year
and Vortech's purchase of them, it's been very hard to get the
1600AX. Now after talking with Vortech at SEMA, it's
obvious that any new production of the Lysholm 1600AX is a ways
off (at least until next summer). Apparently they haven't
even moved the production tooling from Sweeden yet; so who know
when it will be done.
So, we have looked into other options.
First option is the new Eaton TVS 1320, which is a higher
efficiency 4-lobe version of the older Eaton blowers that have
served everyone so well. Only issue is that the TVS
blowers are significantly more expensive, and in fact they are
more like twin-screws in cost; so it's not as simple a decision
as it used to be if you want to save money. Still they
provide great efficiencies because they still don't make any
internal boost; so my sense is that they will be a good
option.... but only testing will tell.
Second option is still the big power option of a
twin-screw charger, and for that we plan to move to the Sprintex
twin-screw superchargers. Sprintex is an Australian
company that has just as good quality and performance numbers as
Lysholm, and they are available in smaller units. The
Sprintex S5-335 is a hair smaller in outer dimensions than the
Lysholm 1600AX (which helps) and smaller displacement too, which
will also help it's application on the RSX. The 335 is
good to 500 hp; so it's still a significant step up from any
Eaton M62 or M90 found on the K-series engines.
Our manifold is moving forward. Below is
the cooler section, which sits low on the front of the engine,
just in front of the starter and above the clutch slave
cylinder. And the manifold runners to the intake ports are
based on the new K24 Si manifold; so they will have exceptional
flow. And lastly the driveshaft across the plenum is now
shorter so vibration issues at the shaft's critical speed are
not a problem as they were on earlier prototypes.

This cooler is the same dimensions as the one
with the red background below, but the cost on the above cooler
is significantly less and performance will be just as good (that
is to say it will be remarkable with it's 4 12" coolers)!!
We will be finishing up the prototype in the next month; so stay
tuned.
*********************************************************
Thursday September 22, 2011
Step 1 complete. New cooler basic design
done. Note driveshaft does not got through this.
That single change has cascaded into many layout improvements
that helps driveshaft durability/cost, endplate complexity
(endplates not shown), SC outflow efficiency, and SC inlet
location. Understanding that we have taken a long time in
development, this change is proving to be an important one.
Today this was sent out for quote; so I hope we receive the
finished prototype in about 6 weeks without many changes.

*********************************************************
Tuesday September 13, 2011
It's been awhile since our last update. We
had delays working with the machine shop to product a good
driveshaft prototype, and in the meantime, we've made some
design changes. These changes allow the driveshaft to be
significantly shorter (~12" between bearings rather than ~18")
and has completely fixed our shaft critical speed and vibration
concerns without needing a center bearing on the shaft (which
causes havoc with proper fitment of 4 cooler cores). As a
result, the supercharger will not sit as close to the driver's
side of the engine bay and the inlet will be an easier fit.
Also, the supercharger outlet positioning appears
to allow a downward exit rather than a sharp 90 degree flow
through the supercharger support bracket; so SC outlet flow
should be a bit more efficient.
*********************************************************
Saturday May 7, 2011
Latest
update
The sc inlet is done. Special attention was
paid to laminar airflow on the short turn into the supercharger
because this is critical airflow area for the inlet. Piping is
thin wall tubular 3" into the throttle body and thicker wall
cast 3" from the throttle body to the supercharger. The
throttle body is low enough to clear the hood without any
problem and high enough to clear the trans linkage just below
it. Testing of inlet air temps will likely dictate a heat
shield between the air filter and the exhaust manifold.

We are still waiting for the prototype driveshaft
to be complete. We are nearing completion of this
prototype finally.
*********************************************************
Thursday April 7, 2011
The driveshaft is out to quote. This design
is for the prototype only because it does not meet our critical
speed requirements. We will be using composite shafts of a
larger diameter in production, but we are moving ahead with the
prototype parts as we have them now in steel.
3D PDF of the shaft is here.
media/Jackshaft Prototype 1 3D.PDF
Now working on the SC inlet. Details coming
soon.
Thanks for your continued interest! We are
working hard to get this done asap!
*********************************************************
Wednesday March 30, 2011
We are working on the driveshaft with a local
machine shop that has experience with high speed generators now.
The driveshaft will take most of the Lysholm elements and adapt
it to work in our longer manifold application. We were
planning to use a steel driveshaft, but the length of the shaft
is such that we are investigating composites because that will
allow the shaft to be narrower (important with the shaft running
through the middle of the manifold). A steel shaft would
have to be 1.25" or greater diameter in order to avoid it's
critical speed frequency (where the shaft naturally starts to
vibrate). We could ignore this design issue, but bearing
play and production tolerances are such that we feel avoiding
the critical speed altogether is important. Our goal is a
17,000 rpm driveshaft capability at 80% of critical speed (a
good safety factor).
Concurrently working on the SC inlet, and we will
have more information about this asap.
*********************************************************
Monday, February 28, 2011
Main
supercharger bracket complete.

Happy to say that we have worked through some
seriously difficult design constraints on the main supercharger
bracket and come out with a winner (I hope...we still need to
test).

Imagine for a moment trying to design a
supercharger support bracket that must position the supercharger
perfectly in line with the thru-manifold jackshaft, that
supports the 20+ lbs of supercharger weight and 50 hp of
supercharger twist, that protects the intake manifold from
weld-cracking forces, that properly collects air and flows air
through the middle of the bracket, and that isn't either too
heavy, too expensive, or (very importantly) too difficult for
the average person to install. Can you imagine the amount
of time you could spend thinking of and trying to apply
different methods to accomplish the above? We are very happy with the design we have now.
Remaining to do: jackshaft/bearings, supercharger
inlet and throttle body setup, manifold support, belt-side snout
support, cooler inlet.
|
